Mazda RX8 - Page 314

(Driver-side
door lock-link
switch)
Driver-side door is
unlocked.
1.0 or less
link switch (See
FRONT DOOR LOCK
ACTUATOR
INSPECTION .)
Driver-side door
key cylinder is
locked.
Approx. 2.5
Driver-side door
key cylinder is
unlocked.
1.0 or less
2S
Lock/unlock
input (Driver-
side door key
cylinder switch)
Driver-side door
key cylinder
switch
Other 5
• Driver-door key
cylinder switch
(See FRONT
DOOR LOCK
ACTUATOR
INSPECTION .)
• Inspect related
harness.
2U
Lock release
power supply
Buckle switch
Within 60 min
after any door is
opened
B+
• Instrument
cluster (See
INSTRUMENT
CLUSTER
INSPECTION .)
• Door switch (See
DOOR SWITCH
INSPECTION .)
• Rear door upper
latch (See REAR
DOOR UPPER
LATCH
SWITCH
INSPECTION .)
• Rear door lower
latch (See REAR
DOOR LOWER
LATCH
SWITCH
INSPECTION .)
• Front buckle
switch (See
FRONT
BUCKLE
SWITCH
INSPECTION .)
• Inspect related
harness.
2W GND Body ground
Under any
condition: Inspect
for continuity to
ground.
Continuity
detected
GND
(w) RX-8 Body
Page 314
