Door lock switch is
locked.
Approx. 2.5
Door lock switch is
unlocked.
1.0 or less
2V
Lock/unlock
input (Door
lock switch)
Door lock switch
Other 5
• Door lock switch
(See DOOR
LOCK SWITCH
INSPECTION .
• Inspect related
harness.
3A HS-CAN+ PCM
Under any
condition: Inspect
wiring harness to
PCM for continuity.
Continuity
detected
-
3B HS-CAN- PCM
Under any
condition: Inspect
wiring harness to
PCM for continuity.
Continuity
detected
-
Ignition switch at
ON
8 or more
3E Tx Coil
Ignition switch at
LOCK or ACC
1.0 or less
• Coil
• Inspect related
harness.
Ignition switch at
ON
8 or more
3F Rx Coil
Ignition switch at
LOCK or ACC
1.0 or less
• Coil
• Inspect related
harness.
