1. Inspect the fuel gauge by setting it to check code 23 of the input/output check mode.(See
INSTRUMENT CLUSTER INPUT/OUTPUT CHECK MODE .)
Water temperature gauge
1. Inspect the water temperature gauge by setting it to check code 25 of the input/output check mode.(See
INSTRUMENT CLUSTER INPUT/OUTPUT CHECK MODE .)
Oil pressure gauge
1. Inspect the oil pressure gauge by setting it to check code 28 of the input/output check mode.(See
INSTRUMENT CLUSTER INPUT/OUTPUT CHECK MODE .)
INSTRUMENT CLUSTER INPUT/OUTPUT CHECK MODE
NOTE:
• In this mode, it is possible to verify the items in the following chart.
Check Code Table
Check code Check item Related items
01 Buckle switch Buckle switch
04 Door switch
• Lights-on reminder warning alarm
• Key reminder warning alarm
• Power door lock system
• Ignition key illumination system
• Interior light control
08 TNS relay
• Lights-on reminder warning alarm
• Each illumination light
12 Speedometer (LCD) Speedometer
13 Tachometer Tachometer
14 Buzzer Buzzer
16 Fuel-level warning light Fuel-level warning light
18 Ignition key illumination Ignition key illumination system
22 Fuel gauge sender unit Fuel gauge
23 Fuel gauge Fuel gauge
25 Water temperature gauge Water temperature gauge
26
• Odometer/tripmeter (LCD) • Odometer/tripmeter (LCD)
