Check code 13 Tachometer operation signal
INSPECTION CONDITION DISPLAY ACTION
The tachometer needle moves full scale
then returns to approx. 3,000 rpm .
The tachometer is
normal.
Except above
After selecting check code 13,
wait for approx. 2 s .

Replace the
instrument cluster.
Check code 14
Check code 14 Buzzer operation signal
INSPECTION CONDITION DISPLAY ACTION
The buzzer sounds. The buzzer is normal.
After selecting check code 14, wait
approx. 2 s .
The buzzer does not
sound.
Replace the instrument
cluster.
Check code 16
Check code 16 Fuel-level warning light flashing signal
INSPECTION CONDITION DISPLAY ACTION
Fuel-level warning light
flashes three times .
The fuel-level warning light
is normal.
After selecting check code 16, wait
approx. 2 s .
Except above
Replace the instrument
cluster.
Check code 18
Check code 18 Ignition key illumination on/off signal
INSPECTION
CONDITION
DISPLAY ACTION
After selecting check
code 18, wait approx. 2 s
.
Ignition key
illumination flashes
three times .
The ignition key illumination is normal.
