DTC TABLE [INSTRUMENT CLUSTER]
DTC Description Page
B1342 Instrument cluster malfunction (See DTC B1342 [INSTRUMENT CLUSTER] )
B2477 Configuration error (See DTC B2477 )
DTC B1342 [INSTRUMENT CLUSTER]
DTC B1342
• Instrument cluster malfunction
DETECTION CONDITION
• Malfunction in the Instrument cluster internal circuit
POSSIBLE CAUSE
• Instrument cluster malfunction
Diagnostic procedure
STEP INSPECTION ACTION
Yes
Replace the instrument cluster. (See INSTRUMENT
CLUSTER REMOVAL/INSTALLATION .)
1
INSPECT INSTRUMENT
CLUSTER
• Clear DTC from memory.
• Turn the ignition switch to
the LOCK position.
• Turn the ignition switch to
the ON position.
• Is B1342 displayed?
No DTC troubleshooting completed.
(w) RX-8 Body
