DTC B2477
DTC B2477
• Configuration error
DETECTION CONDITION
• Configuration error
• Malfunction in the instrument cluster internal circuit
POSSIBLE CAUSE
• Instrument cluster malfunction
Diagnostic procedure
STEP INSPECTION ACTION
Yes
Replace the instrument cluster. (See INSTRUMENT
CLUSTER REMOVAL/INSTALLATION .)
1
PERFORM INSTRUMENT CLUSTER
CONFIGURATION
• Perform instrument cluster
configuration.
• Is B2477 displayed?
No Go to next step.
Yes Go to applicable DTC inspection.
2
VERIFY TROUBLESHOOTING OF
DTC B2477 COMPLETED
• Clear DTC from memory.
• Is B2477 displayed?
No DTC troubleshooting completed.
