PID/DATA MONITOR TABLE [MULTIPLEX COMMUNICATION SYSTEM]
PID name (definition) Condition Specification
PID monitor
module
Terminal
Present
Circuit in the ABS (DSC)
HU/CM is normal.
ABS_MSG
(Missing message from the
ABS (DSC) HU/CM)
Not
Present
Circuit in the ABS (DSC)
HU/CM is disable.
• ABS HU/CM: O,
R
• DSC HU/CM: H,
I
• Instrument
cluster: 1J, 1L
Present
Circuit in the TCM is
normal.
TCM_MSG
(Missing message from the
TCM)
Not
Present
Circuit in the TCM is
disable.
• TCM: 1V, 1Y
• Instrument
cluster: 1J, 1L
Present
Circuit in the EPS control
module is normal
EPS_MSG
(Missing message from the
EPS control module)
Not
Present
Circuit in the EPS control
module is disable
• EPS control
module: 2K, 2M
• Instrument
cluster: 1J, 1L
Present
Circuit in the PCM is
normal.
PCM_MSG
(Missing message from the
PCM)
Not
Present
Circuit in the PCM is
disable.
• PCM: 4S, 4V
• Instrument
cluster: 1J, 1L
Present
Circuit in the TPMS
control module is normal
TPM_MSG
(Missing message from the
TPMS control module)
Not
Present
Circuit in the TPMS
control module is disable
Instrument
cluster
• TPMS control
module: E, G
• Instrument
cluster: 1J, 1L
