PROCEDURES FOR DETERMINING THE LOCATION OF A MALFUNCTION
System Wiring Diagram
1 Wiring harness 1
2 Wiring harness 2
3 Wiring harness 3
4 Wiring harness 4
5 Wiring harness 5
Front harness
6 Wiring harness 6
7 Wiring harness 7
Rear harness
8 Wiring harness 8
9 Wiring harness 9
10 Wiring harness 10
11 Wiring harness 11
12 Wiring harness 12
Instrument panel harness
