MAZE PERGOLAS - Final Drop Screen Attachment

4
Assembly instructions
Pergola Drop Screen
N
R
QTY:1PC
QTY:1PC
QTY:1PC
QTY:1PC
K1
L
10. Install loop (R) and
secure with K1.
9. Fit drop screen to the brackets (ensure
hinge ring bracket is facing inside).
9a: Rotate it
9c: Tighten the
screws
9b: Fit into
correct position
