MAZE PERGOLAS - Page 27

5
Assembly instructions
Pergola Drop Screen
11. Attach the
adjustable holder
(O) to the wire.
12. Fix to column
using screw K3
13. Fix nut from
Q and tighten
14. Fix cover (P)
15. Repeat steps 1-14 for remaining 3x drop sides.
O
K3
QTY:2PCS
QTY:6PCS
QTY:2PCS
QTY:4PCS
P
K2
