General Data
Performance data
Voltage V (DC) 10 – 30 V DC (ext. power supply or SELV power supply, 10-30 V DC, Max. 40A)
Current consumption max. 1300 mA @ 24 V
Random access mem-
ory
Devices with hardware version HW03: 512 MB
Devices with hardware version HW02: 256 MB
IP Protection class IP 30*
* at full occupancy of all connections and interfaces. Alternatively, unused interfaces can be
covered with dust protection plugs.
Area of use Dry environment
Temperature (operat-
ing)
-40 – +75 °C
Temperature (storage) -40 – +85 °C
Humidity 0 – 95% non-condensing
Real-time clock In the event of a power failure, the date and time are maintained for up to 7 days
(depending on the ambient temperature).
Dimensions (max.) 48 mm x 137 mm x 140 mm (W x D x H)
Weight (max.) 650 g
Housing/material Metal
Installation DIN-top hat rail mounting
I/Os and standard interfaces
Digital inputs 4-piece, 1030 V DC (electrically isolated), (low 0 – 3.2 V DC, high 8 – 30 V DC)
Digital Outputs 2-piece, 10-30 V DC (electrically isolated), to a maximum of 1.5 A per output
LAN interfaces 4-piece, 10/100MBit/s full and half duplex operation, automatic detection patch ca-
ble/cross-over cable (auto detection)
USB interfaces USB Host 2.0
SD card slot For SD cards (32.0 mm × 24.0 mm × 2.1 mm) SDHC max. 32 GB; FAT/FAT32
NOTICE
As of firmware version 6.0.5, all mbNET routers, as of hardware version HW03, can use the optional
mbEDGE function.
VPN
VPN protocol IPsec/PPTP/OpenVPN,
64 Tunnel
Encryption method Blowfish, AES,
DES/3DES
MDH 810, MDH 811, MDH 814, MDH 830,
MDH 831, MDH 834, MDH 850 EU, MDH 850
AT&T, MDH 855 EU, MDH 855 AT&T
VPN protocol OpenVPN, 1 Tunnel
Encryption method Blowfish
MDH 815, MDH 816, MDH 819, MDH 835,
MDH 841, MDH 849, MDH 858 EU, MDH 858
AT&T, MDH 859 EU, MDH 859 AT&T
Encryption algorithms MD5, SHA1
Authentication Pre-Shared-Key, X.509
*can only be operated with mbCONNECT24, mymbCONNECT24.hosted, -.virtual, -.mini, -.midi or -.maxi.
Technical data | Page 3 of 7
