MBW 2000 - Page 18

- 15 -
ITEM PART NO. DESCRIPTION QTY
1. 00201 EXCITER HOUSING 1
2. 00206 REAR COVER 1
3. 00259 SHIM, EXCITER (AS REQUIRED)
4. 01004 CYLINDRICAL ROLLER BEARING 1
5. 01070 BALL BEARING 1
6. 01071 RETAINING RING, EXTERNAL 1
7. 01072 FILTER, FELT 1
8. 01099 WASHER 1
9. 01191 RETAINING RING, INTERNAL 1
10. 06096 GASKET 1
11. 06097 GASKET 1
12. 13451 WASHER, 5/8, A325, STRUCTURAL 4
13. 17179 OIL SEAL 1
01002 OIL SEAL, SERIAL NO. 2064574 & LOWER
14. 18696 HHCS, 5/8-11 X 5-3/4, GRADE 8 4
15. 18697 BASEPLATE 1
16. 18701 HEX NUT, 5/8-11, GRADE 8 4
17. 19135 KEY, 1/4” SQ. X 3/4 SQUARE ENDS 1
01283 KEY, 1/4” SQ. X 1-1/4 ROUND ENDS, SERIAL NO. 2064574 & LOWER
18.
19628
FRONT COVER 1
00005 FRONT COVER, SERIAL NO. 2064574 & LOWER
19. 19629 PULLEY, 4-3/8 DIA x 1.0 I.D., AP2000 (ASPHALT VERSION) 1
19630 PULLEY, 3-7/8 DIA x 1.0 I.D., GP2000 (SOIL VERSION & AP2000+) 1
00003
PULLEY, 4-3/8 DIA x 1-1/8 I.D., AP2000 (ASPHALT PLATE) SER. NO. 2064574 & LOWER
00348 PULLEY, 3-7/8 DIA x 1-1/8 I.D., GP2000 (SOIL & 2000+ PLATE) SER. NO. 2064574 & LOWER
20. 19835 EXCITER SHAFT 1
00202 EXCITER SHAFT, SERIAL NO. 2064574 AND LOWER
21. F0205SP SPIROL PIN, 1/8 X 5/8 LG. 1
22. F051806FWS FLANGE LOCKING SCREW, 5/16-18 X 3/4 LG. 6
23. F051808FWS FLANGE LOCKING SCREW, 5/16-18 X 1 LG 7
24. F0612SP PIN, SPIROL 1
25. F0618SPP SOCKET PIPE PLUG, 3/8-18 3
26. F10LW LOCKWASHER, 5/8, ZP 4
SERVICE PARTS:
00062 WASHER SEAL, PULLEY ( NOT SHOWN) SERIAL NO. 2064574 AND LOWER
REPLACEMENT KIT:
19836 EXCITER ASSEMBLY (DOES NOT INCLUDE ITEMS 8, 17, 19 & 23)
19837 EXCITER ASM. ASPHALT (INCLUDES ITEMS 8, 17, 19 & 23) SERIAL NO. 2064574 & BELOW
19838 EXCITER ASM. SOIL (INCLUDES ITEMS 8, 17, 19 & 23) SERIAL NO. 2064574 & BELOW
18757 BOTTOM PLATE, AP/GP2000 (INCLUDES ITEMS: 3, 12, 14, 15, 16, 24, 25 & 26)
