- 17 -
ITEM PART NO. DESCRIPTION QTY
1. 00001 EXCITER HOUSING 1
2. 00006 REAR COVER 1
3. 00066 RETAINER PLATE 1
4. 00259 SHIM EXCITER (AS REQUIRED)
5. 01000 RETAINING RING, INTERNAL 1
6. 01001 RETAINING RING, EXTERNAL 1
7. 01004 CYLINDRICAL ROLLER BEARING 1
8. 01005 SPHERICAL ROLLER BEARING 1
9. 01072 FILTER, FELT 1
10. 01099 WASHER 1
11. 06096 GASKET 1
12. 06098 GASKET 1
13. 17179 OIL SEAL 1
01002 OIL SEAL, SERIAL NO. 3551199 & LOWER
14. 18577 BASE PLATE 1
15. 18700 HHCS, 5/8-11 X 6 GRADE 8 4
16. 18701 HEX NUT, 5/8-11, GRADE 8 ZP 4
17. 19135 KEY, 1/4” SQ. X 3/4 SQUARE ENDS 1
01283 KEY, 1/4” SQ. X 1-1/4 ROUND ENDS, SERIAL NO. 3551199 & LOWER
18.
19628
FRONT COVER 1
00005 FRONT COVER, SERIAL NO. 3551199 & LOWER
19. 19629 PULLEY, EXCITER 4-3/8 DIA x 1.0 I.D. 1
00003 PULLEY, 4-3/8 DIA x 1-1/8 I.D.,
SERIAL NO. 3551199 & LOWER
20. 19912 EXCITER SHAFT 1
18692 EXCITER SHAFT, SERIAL NO. 3551199 & LOWER
21. F0205SP SPIROL PIN, 1/8 X 5/8 LG. 1
22. F051804HCS HEX HEAD CAP SCREW, 5/16-18 X 1/2LG. 3
23. F051806FWS FLANGE LOCKING SCREW, 5/16-18 X 3/4 LG. 6
24. F051808FWS FLANGE LOCKING SCREW, 5/16-18 X 1 LG 7
25. F05BFW WASHER, BRASS, 5/16 1
26. F0612SP SPIROL PIN 1
27. F0618SPP SOCKET PIPE PLUG, 3/8-18
3
28. F10LW LOCKWASHER, 5/8 4
29. F10PW WASHER, 5/8 4
SERVICE PARTS:
00062 WASHER SEAL, PULLEY (NOT SHOWN) SERIAL NO. 2064574 & LOWER
REPLACEMENT KIT
19913 EXCITER ASSEMBLY ( COMPLETE)
18758 BOTTOM PLATE, AP/GP3550 (INCLUDES ITEMS:7. 19, 20, 21, 27, 28, 29 & 30)
