MBW GP3000 - Page 16

- 13 -
ITEM PART NO. DESCRIPTION QTY
1. 00008 HOUSING, GP3000 (Includes items 7, 8, 26 & 27) 1
2. 00014 DECK, GP3000 1
3. 19913 EXCITER, GP3000 1
4. 00025 BRACKET, HANDLE 2
5. 00028 BELTGUARD 1
6. 00034 HANDLE, GP3000 (Includes items 14 & 15) 1
7. 0042L BAR, MOLD LEFT GP3000 1
8. 0042R BAR, MOLD RIGHT GP3000 1
9. 00048 HOOK BOLT 1
10. 00050 APRON, RUBBER GP3000 1
11. 00259 SHIM (as needed)
12. 01011 SHOCKMOUNT 5
13. 01012 SHOCKMOUNT 4
14. 01018 BUSHING, NYLON OUTER 2
15. 01019 BUSHING, NYLON INNER 2
16. 01056 HAIRPIN 2
17. 02462 BAR, ROLL GP3000 (Optional) 1
18. 06054 HEX HEAD CAP SCREW, 5/8-18 x 5-1/2” GR8 4
19. F042006HCS HEX HEAD CAP SCREW, 1/4-20 x 3/4” 3
20. F0420HN HEX NUT, 1/4-20 3
21. F04LW LOCK WASHER, 1/4” 3
22. F04SW WASHER, 1/4” 3
23. F051806FWS FLANGE LOCKING SCREW, 5/16-18 x 3/4” (with Roll Bar only) 8
24. F0518FN FLANGE LOCKING NUT, 5/16-18 (8 with Roll Bar only) 10
25. F061607FWS FLANGE LOCKING SCREW, 3/8-16 x 7/8” 2
26. F061608FWS FLANGE LOCKING SCREW, 3/8-16 x 1” 10
27. F0616FN FLANGE LOCKING NUT, 3/8-16 10
28. F081305HCS HEX HEAD CAP SCREW, 1/2-13 x 5/8” 5
29. F081306HCS HEX HEAD CAP SCREW, 1/2-13 x 3/4” 13
30. F08LW LOCK WASHER, 1/2” 18
31. F10LW LOCK WASHER, 5/8” 4
OPTIONAL ACCESSORIES
01022 SPRINKLING SYSTEM KIT, GP3000
01023 JOB CART, GP3000
01629 TEST MAT
02408 HEAVY DUTY HOUSING, GP3000
02464 ROLL BAR KIT, GP3000 (Includes items 17, 23 & 24)
