4
Safety Rules ................................................................... 3
Product Specifications .................................................... 4
Assembly ........................................................................ 6
Operation ........................................................................ 8
Maintenance Schedule ................................................. 13
Maintenance .............................................................. 13
Service and Adjustments ........................................... 17
Storage ...................................................................... 21
Troubleshooting .........................................................22
CONGRATULATIONS on your purchase of a new riding
mower. It has been designed, engineered and manu fac tured
to give you the best possible dependability and performance.
Should you experience any problem you cannot easily rem-
edy, please contact your nearest authorized service center/
department. We have com pe tent, well-trained tech ni cians
and the proper tools to ser vice or repair this riding mower.
Please read and retain this manual. The instructions will
enable you to assemble and maintain your riding mower
prop erly. Always observe the “SAFETY RULES”.
CUSTOMER RESPONSIBILITIES
• Read and observe the safety rules.
• Follow a regular schedule in maintaining, caring for
and using your riding mower.
• Follow the instructions under “Maintenace” and “Stor-
age” sec tions of this manual.
• Wear proper Personal Protective Equipment (PPE)
while operating this machine, including (at a minimum)
sturdy footwear, eye protection, and hearing protection.
Do not mow in short and/or, open toed footwear.
• Always let someone know you are outside mowing.
WARNING: This riding mower is equipped with an in-
ternal com bus tion engine and should not be used on or
near any un im proved forest-covered, brush-covered or
grass-cov ered land unless the en gine's exhaust system
is equipped with a spark arrester meeting ap pli ca ble local
or state laws (if any). If a spark arrester is used, it should
be maintained in effective working order by the operator.
In the state of California the above is required by law
(Section 4442 of the California Public Resources Code).
Other states may have similar laws. Federal laws apply
on federal lands.
Gasoline Capacity
1.25 Qt. (1,18 L)
and Type: Unleaded Regular
Oil Type SAE 30 (above 32°F/0°C)
(API-SG-SL):
SAE 5W-30(below 32°F/0°C)
Oil Capacity: 20 oz. (0,59 L)
Spark Plug: Champion RC12YC
(Gap: .030"/0,76mm)
Ground Speed Forward: 0-4 mph/6,4 kmh
Reverse: 0-1 mph/1,6 kmh
Blade Bolt Torque: 45-55 Ft. Lbs./ 60-75 Nm
TABLE OF CONTENTS
