1600W SHREDDER
MCS2001
6/8/2009
No. Parts No. Description Q P Code
1 6266-200103 TOP HOPPER 1 150
2 6200-200101 SCREW 5 150
3 6134-200101 KNOB 2 150
4 6024-200101 RESTRAINNIG SPRING 3 150
5 6WSB-08 SPRING WASHER 11 150
6 6014-200101 WASHER 3 150
7 6STBBM05-15 SCREW 5 150
8 6270-200106 BODY 1 150
9 6263-200102 DUST PLATE 1 150
10 6158-200101 CUTTER CLAMP 1 150
11 6134-200102 KNOB 1 150
12 6SDABB04-20 SCREW 2 150
13 6WFZ-08 WASHER 12 150
14 6CE-06 E RING 3 150
15 6SDAZ-04-10 SCREW 2 150
16 6WFZ-04 WASHER 6 150
PARTS LIST
17 6263-200101 DUST PLATE 1 150
18 6WSB-04 SPRING WASHER 10 150
19 6NAZ-04 NUT 2 150
20 6262-200106 RESTRAINING COVER 1 150
21 6SDAZ-05-55 SCREW 1 150
22 6059-200101 BRACKET TUBE 1 150
23 6NAZ-05 NUT 1 150
24 6SXDZ-10-35 SCREW 1 150
25 6WSB-10 SPRING WASHER 1 150
26 6158-200002 CUTTER CLAMP 1 150
27 6156-200001 SQUARE BUSH 1 150
28 6250-200002 V-CUTTER 1 150
29 6267-200001 V-CUTTER BASE 1 150
30 6200-200002 SCREW M10X10 4 150
31 6250-200001 CUTTER (BLADE) 2 150
32 6268-200101 CUTTER BASE 1 150
33 6124-200101 CUTTER BUSH 1 150
34 6200-200001 SCREW M8X18 4 150
35 6WDB-08 SPRING WASHER 4 150
36 6200-200102 SCREW 4 150
37 6207-200102 BRACKET CLAMP 1 150
38 6036-200101 SWITCH HOLDER 1 150
39 6262-200101 SWITCH COVER 1 150
PARTS LIST
