130800S0
WASH BODY SHELL BEFORE PAINTING
WITH WASHING UP LIQUID
REMOVE PROTECTION FILM AFTER PAINTING
!!! CAUTION !!!
AFTER CLEANING / WASHING
LUBRICATE WITH CHAIN GREASE ALL DRIVE COMPONENTS
(CENTRAL DIFF. BEWEL GEAR, DRIVE CUPS, AXELS, STEEL TRANSMISSION GEARS)
130500P0
130700P0
130600P0
DECAL SET
B
C
D
1
2
A
3
2
1
4
B
A
5
6
DWG NO: 005300V4
A4
C
GENERAL VIEW
D
sheet: 1 of 7
MONSTER TRUCK V4 COMPETITION
