2
Fabric Element Management MIB
2-65
McDATA SNMP Support
Description Represents the NxPort index within a conceptual table
FcFxPortMode
Syntax INTEGER
Description The values are defined as follow: unknown(1), fPort(2), flPort(3).
FcBbCreditModel
Syntax INTEGER
Description The values are defined as follow: regular(1), alternate(2).
MIB objects defined in the Fabric Element MIB:
fcFabricName
Type FabricName
Access R
Description The Name_Identifier of the Fabric to which this Fabric Element
belongs.
FcElementName
Type FcNameId
Access R
Description The Name_Identifier of the Fabric Element.
FcFeModuleCapacity
Type FcFeModuleCapacity
Access R
Description The maximum number of modules in the Fabric Element, regardless
of their current state.
Module Table
A table that contains one entry for each module in the Fabric Element,
containing information about the modules
Fabric Element MIB Object Name
