5
ABRADE
PIPE &
FITTING
2
• ABRADE pipe and fitting.
• Remove any loose particles from pipe and fitting.
• Loosely place fitting into the
Pivot Release Master (PRM).
• ALIGN the base of the fitting on
the pipe by applying 100lbs of
force to seat the fitting.
• Tighten the fitting in the PRM.
ALIGN
FITTING
TO PIPE
3
100
PSI
100
PSI
