19
HI TCH FRAME (continued)
19 BH-2510 1/ 4 X 1 HEX BOLT
20 RD-4308 HYDRAULIC HOSE RACK
21 NLT-1008 1” TOP LOCK NUT
22
22
22
PPI -200
PPI -300
PPI -400
HI TCH BASE CAT I I (4012-4016)
HI TCH BASE CAT I I I (4020)
HI TCH BASE CAT I V (4025-4045)
See drawbar hitch diagram
for details
23 BHY-1070 1 X 7 GRADE 8 HEX BOLT
24
24
24
CH-1816
CH-1820
CH-1830
SAFETY CHAIN, 16,100lbs (4012-4030)
SAFETY CHAIN, 20,200lbs (4035)
SAFETY CHAIN, 30,400lbs (4045)
25 RT-2054 BUSHI NG, 1 7/ 8"ODx1 1/ 4"IDx1"
26 RT-3103 SAFETY CHAIN WASHER
27 BHY-1085 1 X 8 1/ 2 GRADE 8 HEX BOLT
28 RT-3144 JACK, SQ-15", 2000#
29
29
BU-1265
BU-1267
1/ 2 x 6 x 5 U-BOLT (4012 – 4030)
1/ 2 x 6 x 7 1/ 4 U-BOLT (4035 – 4045)
30 RD-4306 DOCUMENT TUBE
31 MM-1204 4” HOSE CLAMP
32 NLT-5013 1/ 2-13 TOP LOCK NUT
HI TCH
Key
Part No. Description Notes/ Revisions
1
1
1
PPI -200
PPI -300
PPI -400
HI TCH BASE, CAT. II
HI TCH BASE, CAT. III
HI TCH BASE, CAT. IV
2 PPI-208 HI TCH CLEVIS CAT. I I & I I I only
3 PPI-203 V -PLATE CAT. I I – I V
4 PPI -201 CUSHI ON
5 PPI-202 TOP PLATE, CAT. II
5 PPI-302 TOP PLATE, CAT. III – IV
6 BHY-7525 3/ 4 X 2 1/ 2 GRADE 8 BOLT
7 BHY-7555 3/ 4 X 5 1/ 2 GRADE 8 BOLT CAT. I I & I I I only
8 NLT-7510 3/ 4 TOP LOCK NUT CAT. II & I I I only
