McFarlane RD-4020 - Page 23

23
MAI N FRAME AXLE FOR RD-4035 AND RD-4045 (continued)
Key Part No. Description Notes/ Revisions
1
1
RD-4361
RD-4637
MAIN AXLE CYLINDER ARM (4035)
MAIN AXLE CYLINDER ARM (4045)
2 HYO-2103 CYLINDER CLEVIS PI N, 1 X 3
3 CP-3620 3/ 16 X 2 COTTER PI N
4 NLT-1008 1” – 8 TOP LOCK NUT
5 BHY-1033 1” – 8 X 3 1/ 4 GRADE 8 HEX BOLT
6 RD-4360 MAI N AXLE CYLINDER TRUSS
7 BHY-1065 1” – 8 X 6 1/ 2 GRADE 8 HEX BOLT
8 HYS-1102 CYLINDER LOCK, RD TRANSPORT
9 HYS-1112 1 – 8 X 5 GRADE 8 HEX BOLT W/ PI N HOLE
10 NCJ-1008 1” CASTLE JAM NUT
11 BH-6320 5/ 8 – 11 X 2 GRADE 5 HEX BOLT
12 LW-0063 5/ 8 LOCK WASHER
13 NH-6311 5/ 8 – 11 HEX NUT
14 RD-4626
QT-1133
QT-1132
AXLE MOUNT BRACKET
AXLE MOUNT I NSERT
AXLE MOUNT CAP
15
15
RD-4435
RD-4641
MAIN AXLE ASSEMBLY (4035)
MAIN AXLE ASSEMBLY (4045)
16
16
RD-4433
RD-4715
CARRI AGE COVER PLATE (4035)
CARRI AGE COVER PLATE (4045)
17 BH-3860 3/ 8” - 16 X 6 GRADE 5 HEX BOLT
18 NLT-3816 3/ 8” - 16 TOP LOCK NUT
19
19
RD-4591
RD-4631
MAIN FRAME (4035)
MAIN FRAME (4045)
20 BH-7550 3/ 4 – 10 X 5 GRADE 5 HEX BOLT
21 NLT-7510 3/ 4 TOP LOCK NUT
22 RD-4644 AXLE CARRIAGE PI VOT PIN
23
23
RD-4413
RD-4642
AXLE CARRIAGE ASSEMBLY (4035)
AXLE CARRIAGE ASSEMBLY (4045)
24 BH-5045 1/ 2” – 13 X 4 1/ 2 HEX BOLT
25 NLT-5013 1/ 2” - 13 TOP LOCK NUT
26
26
RT-3180
RD-4416
SPI NDLE, 2 ¾ X 12 ½ (4035)
SPI NDLE, 3 X 12 ½ (4045)
27
27
RT-3181
RD-4580
8 BOLT HUB ASSSEMBLY, 6000 LB (4035)
8 BOLT HUB ASSSEMBLY, 7500 LB (4045)
28
28
12.5L-15 FT
36x16-17.5 14T
TI RE ONLY, F PLY HWY (4035)
TI RE ONLY, 14 PLY (4045)
29
29
RT-2179
RD-4645
RI M, 15X10, 8 BOLT, 5000 LB (4035)
RI M, 17.5X10.5, 8 BOLT, 8000 LB (4045)
