McFarlane RD-4025 - Page 37

37
SPI RAL REEL (continued)
13 BH-5028 1/ 2 – 13 X 2 3/ 4 GRADE 5 HEX BOLT
14 SPR-2353 BEARI NG GUARD, 5/ 8”
15
15
15
SPR-5105
SPR-5106
SPR-5107
SPI RAL REEL BEARI NG ASSEMBLY
SPI RAL REEL BEARI NG HOUSI NG
SPI RAL REEL BEARI NG
16 NLT-5013 1/ 2 - 13 TOP LOCK NUT
17 BHP-6323 5/ 8 X 2 1/ 4 HEX BOLT
18 NLT-6311 5/ 8 - 11 TOP LOCK NUT
19
19
19
19
19
19
19
SPR-5048
SPR-5051
SPR-5058
SPR-5066
SPR-5072
SPR-5080
SPR-5095
SPI RAL REEL BLADE, 48”
SPI RAL REEL BLADE, 51”
SPI RAL REEL BLADE, 58”
SPI RAL REEL BLADE, 66”
SPI RAL REEL BLADE, 72”
SPI RAL REEL BLADE, 80”
SPI RAL REEL BLADE, 95”
Refer to layout diagram for
position and size on each unit.
20
20
20
20
20
20
20
RD-4748
RD-4751
RD-4758
RD-4766
RD-4772
RD-4780
RD-4795
48” SPIRAL REEL
51” SPIRAL REEL
58” SPIRAL REEL
66” SPIRAL REEL
72” SPIRAL REEL
80” SPIRAL REEL
95” SPIRAL REEL
Refer to layout diagram for
position and size on each unit.
