42
WI NG LOCKS
FOR RD-4000 SERIES
RD-4020 RD-4025 – RD-4044
Key Part No. Description Notes/ Revisions
1
RD-4508
RD-4509
RD-4610
RD-4611
MAIN FRAME WI NG LOCK, LEFT (4020)
MAIN FRAME WI NG LOCK, RIGHT (4020)
MAIN FRAME WI NG LOCK (4025, 4030, 4035)
MAIN FRAME WI NG LOCK (4045)
2 RD-4612 WI NG FRAME WI NG LOCK (ALL SIZES)
3 BU-5867 5/ 8 - 11 X 6 X 7 1/ 2 U-BOLT
4 LW-0063 5/ 8 LOCK WASHER
5 NH-6311 5/ 8 – 11 HEX NUT
