McFarlane RD-4030 - Disk Mount and Scrapers Components (continued)

33
7
RD-4457
RD-4638
RD-4639
RD-4429
RD-4430
DI SK MOUNT TUBE, WING, RI GHT (4035)
DI SK MOUNT TUBE, MAIN/ WING, LEFT (4045)
DI SK MOUNT TUBE, MAIN/ WING, RI GHT (4045)
DI SK MOUNT TUBE, WING, LEFT OUTSI DE (4045)
DI SK MOUNT TUBE, WING, RI GHT OUTSI DE (4045)
8 BHY-7535 3/ 4 – 10 X 3 1/ 2 GRADE 8 HEX BOLT
9 RT-2611 DI SK SPRING CLAMP PLATE
10 BH-6325 5/ 8 – 11 X 2 1/ 2 GRADE 5 HEX BOLT
11 NLT-7510 3/ 4 - 10 TOP LOCK NUT
12 NLT-6311 5/ 8 - 11 TOP LOCK NUT
13 RD-4470 DI SK GANG SPRING
14 BHY-7530 3/ 4 – 10 X 3 GRADE 8 HEX BOLT
15 RD-4530 SCRAPER MOUNT BRACKET
16 RD-4472 DI SK BEARING MOUNT
17 BC-6320 5/ 8 – 11 X 2 CARRIAGE BOLT
18 FW-0063 5/ 8 FLAT WASHER
19 RD-4613
RD-4614
RD-4537
RD-4538
RD-4711
RD-4712
RD-4560
RD-4573
RD-4550
RD-4551
RD-4542
RD-4543
RD-4552
RD-4553
RD-4554
RD-4555
RD-4544
RD-4545
RD-4552
RD-4553
RD-4553
RD-4557
RD-4544
RD-4545
RD-4613
RD-4614
SCRAPER MNT ANGLE, LEFT (4012)
SCRAPER MNT ANGLE, RI GHT (4012)
SCRAPER MNT ANGLE, LEFT (4014)
SCRAPER MNT ANGLE, RI GHT (4014)
SCRAPER MNT ANGLE, LEFT (4016)
SCRAPER MNT ANGLE, RI GHT (4016)
SCRAPER MNR ANGLE, LEFT CENTER (4020)
SCRAPER MNT ANGLE, RI GHT CENTER (4020)
SCRAPER MNT ANGLE, LEFT WI NG (4020)
SCRAPER MNT ANGLE, RI GHT WI NG (4020)
SCRAPER MNT ANGLE, LEFT CENTER (4025-4030)
SCRAPER MNT ANGLE, RI GHT CENTER (4025-4030)
SCRAPER MNT ANGLE, LEFT WI NG (4025)
SCRAPER MNT ANGLE, RI GHT WI NG (4025)
SCRAPER MNT ANGLE, LEFT WI NG (4030)
SCRAPER MNT ANGLE, RI GHT WI NG (4030)
SCRAPER MNT ANGLE, LEFT CENTER (4035)
SCRAPER MNT ANGLE, RI GHT CENTER (4035)
SCRAPER MNT ANGLE, LEFT I NSI DE WI NG (4035)
SCRAPER MNT ANGLE, LEFT OUTSI DE WI NG (4035)
SCRAPER MNT ANGLE, RI GHT I NSI DE WI NG (4035)
SCRAPER MNT ANGLE, RI GHT OUTSIDE WI NG (4035)
SCRAPER MNT ANGLE, LEFT CENTER/WI NG (4045)
SCRAPER MNT ANGLE, RI GHT CENTER/ WING (4045)
SCRAPER MNT ANGLE, LEFT OUTSI DE WI NG (4045)
SCRAPER MNT ANGLE, RI GHT OUTSIDE WI NG (4045)
20 BC-4413 7/ 16 – 14 X 1 1/ 4 CARRIAGE BOLT
21 FW-0044 7/ 16 FLAT WASHER
22 NLT-4414 7/ 16 - 14 TOP LOCK NUT
23 RD-4531 SCRAPER ARM
24 BC-3810 3/ 8 – 16 X 1 CARRIAGE BOLTS
25 NLT-3816 3/ 8 – 16 TOP LOCK NUTS
26 RD-4532 SCRAPER
