44
WHEEL LI FT HYDRAULI CS
FOR RD-4012, 4014 AND 4016
Key Part No. Description Notes/ Revisions
1 HYH-3236 1/ 2” X 236” HYDRAULIC HOSE (w/ one ½ ” pipe end)
2 HYH-3200 1/ 2” X 200” HYDRAULIC HOSE (w/ one ½ ” pipe end)
3 HYH-2094 1/ 2” X 94” HYDRAULI C HOSE
4 HYO-4002 1/ 2” TEE NUT
5 HYF-1222 TEE (1/ 2”m – 1/ 2”m – 1/ 2”m)
6 HYH-2024 1/ 2” X 24” HYDRAULI C HOSE
7
HYH-2070
HYH-2074
1/ 2” X 70” HYDRAULIC HOSE (4012-4014)
1/ 2” X 74” HYDRAULIC HOSE (4016)
8 HYF-2220 ELBOW (1/ 2”m – 1/ 2” o-ring)
9 HYF-3220 ADAPTER (1/ 2”m – 1/ 2” o-ring)
10 HYO-2103 CYLINDER CLEVIS PI N, 1 X 3 1/ 2
11 HYA-33008 3” X 8” CYLINDER, ASAE
12 HYF-2022 ELBOW (1/ 2”m – 1/ 2” f)
13 HYO-3021 HYDRAULIC STOP VALVE
HYO-1201 CONSI STS OF 14, 15, 16 AND 17
14 HYO-1206 HYDRAULIC CLAMP WELD PLATE, 1/ 2
15 HYO-1202 HYDRAULIC CLAMP BODY, 1/ 2 (3/ 4 O.D.)
16 HYO-1204 HYDRAULIC CLAMP COVER, 1/ 2
17 HYO-1208 HYDRAULIC CLAMP BOLT, 1/ 2 (1 3/ 4)
18 HYF-4002 HYDRAULIC DI SCONNECT
HYDRAULI C CYLI NDER SEAL KI TS
639564 SEAL KIT FOR HYA-4008 CYLINDER MONARCH
