SYSTEM SPECIFICATION :
Connectivity Bluetooth 4.0, Wi-Fi (Wi-Fi Bridge required)
Identification Mode
TTLock App, Fingerprint, Card (Mifare 13.56
MHz), Code and Bluetooth
User Capacity
200
Identification Time Instant recognition under 0.3 seconds
Code User-defined 4-8 digit
Keypad Backlight Yes
Temporary Code or Ekey Yes
Compatible Smartphone iOS7.0 or above, Android 4.4 or above
Remote Access Yes, Wi-Fi Gateway
Mechanical Key Override Yes
Micro-USB Backup Power Interface Yes
Working Voltage 6 V (4 X Alkaline AA Batteries)
Working Temperature
External Assembly: -4 °F ~ 149 °F (-20 °C ~ 65
°C)
Internal Assembly: 14 °F ~ 131 °F (-10 °C ~ 55
°C)
Battery Life Up to 12 months (10,000 times access)
Compatible Smart Home Eco-system
Alexa and Google Assistant (Wi-Fi Gateway is
required)
Hardware Type Lever
Door Thickness 38 - 55 mm
Door Handing Reversible (Left and Right)
8
Case Material Aluminium Alloy
IP Rating (IP65 External Lock Housing) (IP54 Internal Lock Housing)
Finish Satin Nickel or Black
Warranty Refer to McGrath locks Warranty form
Available Mortice 60mm
Tubular Latch 60mm,70mm
Working Humidity 10%~95%
Factory Passcode 123456, after setting, factory passcode will be invalid
WiFi Gateway Available(Optional)
Unlock time 1-1.5 seconds
Dynamic current <200mA
Static current 45uA
Administration Number 9
Fingerprint Capacity 100
Card Capacity 50
Pin code Capacity 1 Master 49 users
Bluetooth capacity Unlimited
MLNX6
