System Specification :
Material 5# Zinc alloy,304#stainless steel, ABS
Available Colour Black
Door Thickness 37mm – 47mm
Communication Bluetooth 4.1 BLE and above
Support OS iOS 7.0 or above, Android 4.4 or above
Battery Life 18 Month
Power Supply DC 4.5V – 8V: 4pcs AA alkaline batteries
Static Current < 65uA
Motor working current <200mA
Unlock Way M1 card, Passcode, APP, Wristband, Mechanical Key
Unlock Time 1-1.5seconds
Working Temperature -20~70 degree
Working Humidity 10%~95%
IP Class (IP66 External Lock Housing) (IP54 Internal Lock
Housing)
Available Mortise Dormakaba MS2602, MS2902
WiFi Gateway Available
Warranty Refer to McGrath locks Warranty form
Packing Carton box with EPE inside
4
Admin capacity 1
User code capacity 150
User card capacity 200
APP shared code Unlimited
Length of password iOS 7.0 or above, Android 4.4 or above
Card working
frequency
13.56MHZ
RFID card type Mifare1 card, support S50 and S70
Fire rating 2 hours fire rated at 1050 degrees
Fire Certificates On request
Fire rating Certificate
No.
FRT210244 R1.0, FRT210213 R1.0
Fire Rating Doors E-Core, Firecore
MLWINDSOR Digital Lock
