Midrange/Tweeter Column Rear Panel and Low Frequency Column Base Connections
MIDRANGE/HIGH Frequency
Column 16 pin Connector, con-
nects to the 16 pin plug and
cable coming from the LOW
Frequency Column Base
The 16 pin plug and cable at
the front bottom of the LOW
Frequency Column Base con-
nects to the MIDRANGE/
HIGH Frequency Column 16
pin Connector
