CX-153MONOFOURTH-WAY
Whenmonofourth-wayoperationisdesiredwiththeCX-153thereisnopatchcordsrequired.Plugtheline-in
intoINPUT1.AttachcablefromLOWOUT1tothesubfrequencyamplifier.DonotanythingintoHIGH
OUT1orINPUT2.Modeswitchpushmono.Thesejacksareautomationnormallledwhennothingisplugged
intothem.AttachacableLOWOUT2totheLOWamplifier.AttachacablefromMID1tothemidrange
frequencyamplifier.AttachacablefromHIGH1tothehighfrequencyamplifier.
(CAUTION:JUSTPLACEINTOMONOONMODESWITCHPUSH.)
INPUT1-MAININPUTLEVELCONTROL
LOW1-
MID1-MIDFREQUENCYAMPLIFIERLEVELCONTROL
HIGH1-HIGHFREQUENCY
LOW/MIDFREQ.1-MIDOUTPUTRANGE,LOWCUTOFFFREQUENCY.
MID/HIGHFREQ1-MID/HIGHFREQ.
INPUT2-SETTO0
LOW2-SUBFREQUENCYAMPLIFIERLEVELCONTROL
MID2-LOWFREQUENCY
HIGH2-SETTO0AND
LOW/MIDFREQ2-SUB/LOWFREQ.
MID/HIGHFREQ2-LOWOUTPUTRANGE,HIGHCUTOFFFREQUENCY.
SETTO0ANDLOW1MUTE
AMPLIFIERLEVELCONTROL
AMPLIFIERLEVELCONTROL
SOURCE
LINE-IN
HIGHAMP
1
0
POWER
LOWAMP
1
0
POWER
MIDAMP
1
0
POWER
1
0
SUBAMP
1
0
POWER
6
