CX-154STEREOFOURTH-WAY
Whenstereofourth-wayoperationisdesiredwiththeCX-154.Therearenopatchcordsrequired.Plugtheleft
line-inandtherightlineintoinput1andinput2respectively.FromtheSUBOUT1andSUBOUT2attacha
cabletotheinputoftheleftandrightsubfrequencyamplifiers.FromtheLOWOUT1andLOWOUT2attach
acabletotheinputoftheleftandrightlowfrequencyamplifiers.FromtheMIDOUT1andMIDOUT2
attachacabletotheinputoftheleftandrightmidfrequencyamplifiers.FromtheHIGHOUT1andHIGH
OUT2attachacabletotheinputoftheleftandrighthighfrequencyamplifiers.
FrequencyResponse
LowFrequencyOutput+0-0.5dB10Hz
HighFrequencyOutput=0-1dB20kHz
TotalHamonicDistortion
RL>2kohms
Low
Specifications
FrequencyOutput<0.01%THD
HighFrequencyOutput<0.02%THD
MaximumOutputLevel
RL>2kohms+21dBu(6.2volts)@
<0.5%THD20-20kHz
MaximumVoltageGain6dB
Constant-DirectivityCorrection+3dB@3.5kHzrisingat
6dB/octaveto22.5kHz
SOURCE
LINE-IN
HIGHAMP
1
0
POWERVOL
LOWAMP
1
0
POWER
MIDAMP
1
0
POWER
1
0
SUBAMP
1
0
POWER VOL VOL VOL VOL VOL VOL VOL
RIGHT LEFT RIGHT LEFT RIGHT LEFTRIGHT LEFT
7
