Mcombo 6151-9019 - Page 7

09 10
Assembly of Chair Arms
J*8 L*1
Step 5
1. Connect the Arm Plate #I to the Arm frame with Screws #J as shown.
2. Use Bolts #J to install Right & Left Armrest on the Arm Plates #I.
Now you have all installed it. Relax your body on this chair and even decorate your living room.
Congratulations!
J
L
J
D1
D2
L
1. Fix the arm plate #I with 2 screws #J from above
2. Connect the arm plate #I to #D with 2 screws #J from the bottom
I I
I
J
D
D
J
1 2 3
!
