24 AGZ 026B through 130B IOMM AGZ-5
Table 13, Packing List
Description Part Number Bubble Number
Vertical Support Rib 074758501 1
Top Cover 330409401 2
Front Panel 330409501 3
¼ - 20 x ½” Screw (Place in Poly Bag) 046093807
Figure 21, Components
VERTICAL SUPPORT RIB TOP COVER FRONT PANE
L
REAR (AGAINST UNIT)
T
O
P
Rib
,
Install Firs
t
Front Panel, Install Second
Top Panel, Install Last
Overlap the Front panel
