COOLING (R407C)
MODEL : MDB150DR2 vs. M4MC075DR x 2
Indoor WB Outdoor DB, °C
°C 19.4 25 30 35 40 46 50 52 54
13.9
12,736 13,927 14,991 16,055 17,118 18,395 19,246 19,671 20,097
15
12,869 14,086 15,172 16,258 17,344 18,648 19,517 19,951 20,386
16.7
13,075 14,331 15,452 16,573 17,694 19,039 19,936 20,384 20,832
18
13,233 14,518 15,666 16,813 17,961 19,338 20,256 20,715 21,174
19.4
13,403 14,487 15,456 16,424 17,895 19,660 20,837 21,425 22,013
20
13,475 14,792 15,968 17,144 18,320 19,731 20,671 21,142 21,612
22
13,718 15,033 16,208 17,382 18,557 19,966 20,906 21,375 21,845
22.2
13,742 15,057 16,232 17,406 18,580 19,990 20,929 21,399 21,869
24
13,960 15,274 16,447 17,621 18,794 20,202 21,140 21,609 22,079
MODEL : MDB200DR2 vs. M4MC100DR x 2
Indoor WB Outdoor DB, °C
°C 19.4 25 30 35 40 46 50 52 54
13.9
17,200 18,554 19,763 20,972 22,181 23,632 24,599 25,083 25,566
15
17,280 18,746 20,054 21,363 22,671 24,242 25,288 25,812 26,335
16.7
17,404 19,042 20,504 21,966 23,429 25,184 26,354 26,939 27,524
18
17,498 19,268 20,848 22,428 24,008 25,904 27,168 27,800 28,432
19.4
17,600 18,857 19,978 21,100 23,636 26,680 28,709 29,724 30,738
20
17,644 19,526 21,207 22,888 24,568 26,585 27,930 28,602 29,274
22
17,789 19,575 21,169 22,762 24,356 26,269 27,544 28,182 28,819
22.2
17,804 19,579 21,165 22,750 24,335 26,237 27,506 28,140 28,774
24
17,935 19,623 21,130 22,637 24,144 25,953 27,159 27,762 28,364
MODEL : MDB250DR2 vs. M4MC125DR x 2
Indoor WB Outdoor DB, °C
°C 19.4 25 30 35 40 46 50 52 54
13.9
20,120 21,935 23,555 25,175 26,795 28,739 30,035 30,683 31,331
15
20,304 22,135 23,769 25,404 27,038 28,999 30,307 30,961 31,614
16.7
20,589 22,444 24,101 25,757 27,414 29,401 30,727 31,389 32,052
18
20,806 22,681 24,354 26,027 27,701 29,709 31,048 31,717 32,386
19.4
21,041 22,699 24,180 25,660 27,651 30,040 31,633 32,429 33,225
20
21,141 23,056 24,766 26,476 28,186 30,238 31,606 32,290 32,974
22
21,476 23,460 25,232 27,003 28,774 30,900 32,317 33,026 33,734
22.2
21,510 23,501 25,278 27,056 28,833 30,966 32,388 33,099 33,810
24
21,811 23,864 25,697 27,530 29,362 31,562 33,028 33,761 34,494
MODEL : MDB300DR2 vs. M4MC150DR x 2
Indoor WB Outdoor DB, °C
°C 19.4 25 30 35 40 46 50 52 54
13.9
27,006 29,337 31,418 33,499 35,580 38,078 39,743 40,575 41,408
15
27,212 29,659 31,843 34,028 36,213 38,834 40,582 41,456 42,330
16.7
27,531 30,156 32,501 34,845 37,190 40,003 41,879 42,817 43,754
18
27,774 30,537 33,004 35,470 37,937 40,897 42,871 43,857 44,844
19.4
28,036 30,177 32,087 33,998 37,572 41,860 44,719 46,148 47,578
20
28,149 31,034 33,610 36,187 38,763 41,854 43,915 44,946 45,976
22
28,524 31,326 33,829 36,331 38,833 41,836 43,838 44,839 45,840
22.2
28,561 31,355 33,850 36,345 38,840 41,834 43,830 44,828 45,826
24
28,898 31,618 34,047 36,475 38,903 41,818 43,760 44,732 45,703
All power units in watts
