16 IM 865
TABLE E: AUXILIARY HEATER KITS CHARACTERISTICS AND APPLICATION
MAX. FUSE OR HEATER KIT AIR CONDITIONER
CKT. BKR. MAX. FUSE OR AIR MAX. FUSE
UNIT HEATER KIT HEATER KW HEATER KIT UNIT MIN. CKT. SIZE (CKT. BKR. HEATER KIT CKT. BKR. SIZE CONDITIONER OR CKT. BKR.
MODEL MODEL NO. @ 208/240* FLA AMPACITY MUST BE MIN. CKT. (CKT. BKR. MUST MIN. CKT. SIZE (CKT. BKR.
NUMBER HACR TYPE FOR AMPACITY BE HACR TYPE AMPACITY MUST BE HACR
USA) FOR USA) TYPE FOR USA)
NONE — — 34/34 40/40 — — 34/34 40/40
A06C 4.2/5.6 11.7/13.5 34/34 40/40 15/17 15/20
A10C 7.2/9.6 20.0/23.1 34/37 40/40 25/29 25/30
A11C 7.2/9.6 20.0/23.1 34/37 40/40 25/29 25/30
MPS006AYCL A12C 8.4/11.2 23.4/27.0 37/41 40/45 30/34 30/35
A15C 10.8/14.4 30.1/34.7 45/51 45/60 38/44 40/45
A20C 14.4/19.2 40.1/46.2 58/65 60/70 50/58 50/60
A21C 14.4/19.2 40.1/46.2 58/65 60/70 50/58 50/60
A24C 18.0/24.0 50.1/57.8 70/80 70/80 63/73 70/80
NONE — — 34/34 40/40 — — 34/34 40/40
A06C 4.2/5.6 11.7/13.5 34/34 40/40 15/17 15/20
A10C 7.2/9.6 20.0/23.1 34/37 40/40 25/29 25/30
A11C 7.2/9.6 20.0/23.1 34/37 40/40 25/29 25/30
MPS006AYCM A12C 8.4/11.2 23.4/27.0 37/41 40/45 30/34 30/35
A15C 10.8/14.4 30.1/34.7 45/51 45/60 38/44 40/45
A20C 14.4/19.2 40.1/46.2 58/65 60/70 50/58 50/60
A21C 14.4/19.2 40.1/46.2 58/65 60/70 50/58 50/60
A24C 18.0/24.0 50.1/57.8 70/80 70/80 63/73 70/80
NONE — — 18 20 — — 18 20
A06D 5.6 6.7 18 20 9 10
A10D 9.6 11.6 18 20 15 15
A11D 9.6 11.6 18 20 15 15
MPS006AYDL A12D 11.2 13.5 21 25 17 20
A15D 14.4 17.3 26 30 22 25
A20D 19.2 23.1 33 35 30 30
A21D 19.2 23.1 33 35 29 30
A24D 24.0 28.9 40 40 37 40
NONE — — 18 20 — — 18 20
A06D 5.6 6.7 18 20 9 10
A10D 9.6 11.6 18 20 15 15
A11D 9.6 11.6 18 20 15 15
MPS006AYDM A12D 11.2 13.5 21 25 17 20
A15D 14.4 17.3 26 30 22 25
A20D 19.2 23.1 33 35 30 30
A21D 19.2 23.1 33 35 29 30
A24D 24.0 28.9 40 40 37 40
NONE — — 14 15 — — 14 15
A15Y 14.4 13.9 21 25 18 20
MPS006AYYL A20Y 19.2 18.5 26 30 24 25
A24Y 24.0 23.1 32 35 29 30
NONE — — 14 15 — — 14 15
A15Y 14.4 13.9 21 25 18 20
MPS006AYYM A20Y 19.2 18.5 26 30 24 25
A24Y 24.0 23.1 32 35 29 30
