McQuay MDB075D User Manual

28
All the data above are based on 26.7°C entering DB. To obtain data for different entering DB, please use the
formula below :
Sensible capacity (@EDB) (kW) = Sensible capacity (@26.7) + 1.23 x L/s x (1 - BPF) ( EDB - 26.7 ) / 1000
Where, BPF = Bypass factor
EDB = Entering dry bulb temperature, ° C
Indoor MDB075D MDB100D MDB125D
Outdoor MMC075D MMC100D MMC125D
Bypass Factor
0.38 0.42 0.39
Indoor MDB125D2 MDB150D MDB150D2 MDB200D2
Outdoor MLC061C x 2 MMC075D MMC075D x 2 MMC100D x 2
Bypass Factor
0.46 0.39 0.38 0.42
Indoor MDB250D2 MDB300D2 MDB400D4 MDB500D4
Outdoor MMC125D x 2 MMC150D x 2 MMC100D x 4 MMC125D x 4
Bypass Factor
0.39 0.39 0.42 0.39
