McQuay MDB075D User Manual

57
HEATING (R22)
MODEL : MDB075DR vs. MMC075DR
Indoor WB Outdoor DB, °C
°C 19.4 25 30 35 40 46 50 52 54
13.9
6,508 7,068 7,567 8,067 8,567 9,166 9,566 9,766 9,966
15
5,716 6,352 6,921 7,489 8,057 8,739 9,194 9,421 9,648
16.7
5,883 6,498 7,047 7,596 8,145 8,804 9,244 9,463 9,683
18
6,011 6,609 7,144 7,678 8,213 8,854 9,282 9,496 9,709
19.4
6,148 6,879 7,532 8,184 8,422 8,708 8,899 8,994 9,089
20
6,207 6,794 7,317 7,840 8,364 8,992 9,411 9,620 9,829
22
6,404 7,007 7,547 8,086 8,625 9,271 9,703 9,918 10,134
22.2
6,423 7,029 7,569 8,110 8,651 9,299 9,732 9,948 10,164
24
6,956 7,611 8,196 8,780 9,365 10,066 10,534 10,768 11,002
MODEL : MDB100DR vs. MMC100DR
Indoor WB Outdoor DB, °C
°C 19.4 25 30 35 40 46 50 52 54
13.9
8,430 9,105 9,708 10,311 10,913 11,637 12,119 12,360 12,601
15
7,570 8,266 8,888 9,510 10,132 10,878 11,375 11,624 11,872
16.7
7,678 8,400 9,044 9,689 10,333 11,107 11,622 11,880 12,138
18
7,761 8,502 9,164 9,826 10,487 11,282 11,811 12,076 12,340
19.4
7,850 8,762 9,576 10,390 10,958 11,640 12,095 12,322 12,549
20
7,888 8,651 9,332 10,013 10,694 11,511 12,056 12,328 12,600
22
8,016 8,780 9,463 10,145 10,828 11,647 12,193 12,466 12,739
22.2
8,028 8,793 9,476 10,159 10,841 11,661 12,207 12,480 12,753
24
8,832 9,663 10,405 11,147 11,889 12,780 13,373 13,670 13,967
MODEL : MDB125DR vs. MMC125DR
Indoor WB Outdoor DB, °C
°C 19.4 25 30 35 40 46 50 52 54
13.9
8,846 9,501 10,085 10,669 11,254 11,955 12,422 12,656 12,890
15
8,817 9,693 10,475 11,256 12,038 12,976 13,602 13,915 14,227
16.7
8,984 9,888 10,694 11,501 12,308 13,276 13,922 14,244 14,567
18
9,112 10,037 10,863 11,688 12,514 13,505 14,166 14,496 14,827
19.4
9,249 9,761 10,217 10,674 11,880 13,327 14,292 14,774 15,256
20
9,308 10,252 11,094 11,936 12,779 13,789 14,463 14,800 15,137
22
9,505 10,433 11,262 12,090 12,919 13,914 14,577 14,908 15,240
22.2
9,524 10,451 11,278 12,106 12,933 13,926 14,588 14,919 15,250
24
9,073 9,927 10,689 11,452 12,214 13,129 13,739 14,044 14,349
MODEL : MDB125DR2 vs. MLC061CR x 2
Indoor WB Outdoor DB, °C
°C 19.4 25 30 35 40 46 50 52 54
13.9
8,370 8,791 9,167 9,544 9,920 10,371 10,672 10,823 10,973
15
8,629 9,468 10,217 10,967 11,716 12,616 13,215 13,515 13,815
16.7
8,781 9,648 10,422 11,196 11,970 12,899 13,519 13,828 14,138
18
8,897 9,786 10,579 11,372 12,165 13,116 13,751 14,068 14,385
19.4
9,023 9,108 9,184 9,260 10,460 11,900 12,860 13,340 13,820
20
9,077 9,985 10,795 11,606 12,417 13,390 14,038 14,362 14,687
22
9,256 10,154 10,956 11,757 12,559 13,521 14,163 14,483 14,804
22.2
9,274 10,171 10,972 11,772 12,573 13,534 14,175 14,495 14,816
24
7,871 8,612 9,273 9,935 10,596 11,390 11,919 12,184 12,448
All power units in watts
