McQuay MQS-174018-CFC216A User Manual

DC Inverter U-match Series Floor Ceiling Type Unit
12
4.3 Connection Pipe Requirement
CAUTION!
The maximum length of the connection pipe is listed in the Table below. Do not place the units
between which the distance exceeds the maximum length of the connection pipe.
Table 3.3
Item
Model
Size of Fitting
Pipe(Inch)
Max. Pipe
Length (m)
Max. Height
Difference between
Indoor Unit and
Outdoor Unit (m)
Drainage pipe(Outer
Diameter × wall
thickness) (mm)
Liquid
Gas
MQS-174018-CFC216A
MQIU-174018-HCU216A
1/4
1/2
20
15
φ17×1.75
3/8
5/8
30
15
φ17×1.75
3/8
5/8
30
15
φ17×1.75
3/8
5/8
50
30
φ17×1.75
3/8
3/4
50
30
φ17×1.75
Notes:
①
. The connecting pipe should be thermally insulated properly.
②
. The pipe wall thickness shall be 0.5-1.0 mm and the pipe wall shall be able to
withstand the pressure of 6.0 MPa. The longer the connecting pipe, the lower
the cooling and heating effect performs.
③
. The pipe wall thickness shall be 0.5-1.0 mm and the pipe wall shall be able to
withstand the pressure of 6.0 MPa. The longer the connecting pipe, the lower
the cooling and heating effect performs.
4.4 Electrical Requirement
Electric Wire Size and Fuse Capacity.
Table 3.4
Indoor Units
Power Supply
Fuse Capacity
Breaker
Capacity
Min. Power
Supply Cord
V/Ph/Hz
A
A
mm
2
18K~60K
220-240V~ 60Hz
5
6
1.0
MQS-1740 24-CFC216A
MQIU-174024-HCU216A
MQS-1740 36-CFC216A
MQIU-174036-HCU216A
MQS-1740 48-CFC216A
MQIU-174048-HCU216A
MQS-1740 60-CFC216A
MQIU-174060-HCU216A
