McQuay MWM 007G User Manual

100
Outdoor Unit
Model: MLC 009C
No Descriptions Part No No Descriptions Part No
1
A
ssy., Base Pan
A
50014057372 11 Right Panel
A
01014052509
2
A
ssy., Condenser Coil
A
50024059248 12
A
ssy. Control Panel
A
50044054806
3 Valve Bracket
A
01014051164 13
A
ssy., Front Panel
A01014052512
4 Compressor
A
50049016211 14
A
ssy., Valve Cover
A50124055172
5 Assy., Partition A50064065275 15 Assy., Front Grille A50124056905
6
A
ssy., Cap Tube
A
50024064154 16 Plastic, Handle
A
12014057948
7 Bracket, Fan Motor A01014052516 17 Rubber Grommet A11059016218
8 Fan Motor
A
03039015324 18
A
ssy., Flare Valve 2 Ways 1/4"
A50054054950
9 Fan Blade
A
03019004131 19
A
ssy., Flare Valve 3 Ways 3/8"
A50054054951
10 Left Panel
A
01014052510
