Model: MLC 010C / 015C
No Descriptions Part No No Descriptions Part No
1
A
ssy., Base Pan
A
50014051158 11 Right Panel
A
01014051167
2
A
ssy., Condenser Coil
A
50024052499 12
A
ssy., Front Panel
A
01014051171
3 Valve Bracket
A
01014051164 13
A
ssy. Control Panel
4 Compressor MLC 010C A50044058195
MLC 010C
A
04019019550 MLC 015C
A
50044057994
MLC 015C
A
50049019125 14
A
ssy., Valve Cover
A
50124051173
5
A
ssy., Partition
A
50064055063 15
A
ssy., Front Grille
A
50124056700
6
A
ssy., Cap Tube 16 Plastic, Handle
A
12014057948
MLC 010C A50024056101 17 Rubber Grommet
MLC 015C
A
50024054807 MLC 010C
A
11059000271
7 Bracket, Fan Motor
A
01014051162 MLC 015C
A
11054000272
8 Fan Motor 18
A
ssy., Flare Vlave 2 Ways 1/4"
A
50054054950
MLC 010C A03039016104 19 Assy., Flare Valve 3 Ways 3/8"
MLC 015C A03039015323 MLC 010C
A50054054951
9 Fan Blade
A
03019015339
A
ssy., Flare Valve 3 Ways 1/2"
10 Left Panel A01014051166 MLC 015C A50054054949
