Model: MLC 009CR
No Descriptions Part No No Descriptions Part No
1
A
ssy., Base Pan
A
50014057372 10 Fan Blade
A
03019004131
2
A
ssy., Condenser Coil
A
50024064204 11 Left Panel
A
01014052510
3 Valve Bracket
A
01014051164 12 Right Panel
A
01014052509
4 Compressor 13
A
ssy. Control Panel
A
50044059032
MLC 009CR A50049016211 14 Assy., Front Panel
A01014052512
5
A
ssy., Partition
A
50064065275 15
A
ssy., Valve Cover
A50124055172
6 Assy., 4 Way Vlave 16 Assy., Front Grille A50124056905
MLC 009CR
A
50024065011 17 Plastic, Handle
A
12014057948
7
A
ssy., Cap Tube 18 Rubber Grommet
A
11059016218
MLC 009CR
A
50024065046 19
A
ssy., Flare Valve 2 Ways 1/4"
A50054054950
8 Bracket, Fan Motor
A
01014052516 20
A
ssy., Flare Valve 3 Ways 3/8"
A50054054951
9 Fan Motor
A
03039015324 21 Sensor, Outdoor Defrost
A
50134039416
