Model: MLC 010CR / 015CR
No Descriptions Part No No Descriptions Part No
1
A
ssy., Base Pan
A
50014051158 11 Left Panel
A
01014051166
2 Assy., Condenser Coil 12 Right Panel A01014051167
MLC 010CR
A
50024065601 13
A
ssy., Front Panel
A
01014051171
MLC 015CR A50024060071 14 Assy. Control Panel
3 Valve Bracket
A
01014051164 MLC 010CR
A
50044059033
4 Compressor MLC 015CR A50044059034
MLC 010CR
A
04019019550 15
A
ssy., Valve Cover
A50124051173
MLC 015CR A04019019125 16 Assy., Front Grille
A50124056700
5
A
ssy., Partition
A
01014051165 17 Plastic, Handle
A
12014057948
6 Assy., 4 Way Valve A05019004157 18 Rubber Grommet
7 Assy., Cap Tube MLC 010CR A11059000271
MLC 010CR
A
50024065311 MLC 015CR
A
11054000272
MLC 015CR A50024064508 19 Assy., Flare Valve 2 Ways 1/4" A50051054950
8 Bracket, Fan Motor
A
01014051162 20
A
ssy., Flare Valve 3 Ways 3/8"
9 Fan Motor MLC 010CR
A50054054951
MLC 010CR A03039016104 Assy., Flare Valve 3 Ways 1/2"
MLC 015CR
A
03039015323 MLC 015CR
A50054064042
10 Fan Blade
A
03019015339 21 Sensor, Outdoor Defrost
A
50134039416
