Model: M4LC 020B / 025B
No. Descriptions Part No No. Descriptions Part No
1 Back Grille
A
50014043394 11
A
ssy., Cap. Tube
2 Top Panel
A
01010011397 M4LC 020B
A
50024043567
3
A
ssy., Condenser Coil M4LC 025B
A
50024043576
M4LC 020B
A
50024043566 12
A
ssy., Partition
A
50014012920
M4LC 025B
A
50024043575 13
A
ssy., Terminal Box Panel
A
01014047406
4 Bracket, Motor Mounting
A
01010011398 14
A
ssy., Side Panel
A
01010011395
5 Fan Motor
A
03039000057 15
A
ssy., Access Panel
A
50124017615
6 Fan Blade
A
03019000016 16 Flare Valve Mounting Plate
A
01014036061
7 Assy., Front Panel A50014045826 17 Flare valve 3-way 5/8" A50059014488
8 Compressor 18 Flare Valve 2-way 1/4"
M4LC 020B A04019010653 M4LC 020B A50059014482
M4LC 025B
A
04019010654 Flare Valve 3-way 3/8"
9 Rubber Gromme
t
A
11054000271 M4LC 025B
A
50059014483
10
A
ssy., Base Pan
A
50014013143
