McQuay MWM 007G User Manual

110
Model: M4LC 007BR / 010BR / 015BR
No Descriptions Part No No Descriptions Part No
1 Back Grille
A
50014041357 11
A
ssy., Base Pan
A
50014013142
2 Top Panel
A
01010011408 12
A
ssy., Restrictor Valve
3 Assy., Condenser Coil M4LC 010BR A50024043723
M4LC 007 / 010BR A50024032349 Assy., Cap. Tube
M4LC 015BR
A
50024043730 M4LC 007BR
A
50024052141
4 Bracket, Motor Mounting
A
01010011413 M4LC 015BR
A
50024037680
5 Fan Motor 13
A
ssy., Partition
A
50014012880
M4LC 007 / 010B
R
A
03039004777 14
A
ssy., Terminal Box Panel
A
01014047405
M4LC 015BR
A
03039000056 15
A
ssy., Side Panel
A
01010011410
6 Fan Blade A03019004131 16 Assy., Access Panel A50124017615
7
A
ssy., Front Panel
A
50014045925 17 Flare Valve Mounting Plate
A
01014017453
8 Assy., 4 Way Valve A05019004157 18 Sensor, Outdoor Defrost A50134039416
9 Compressor 19
A
ssy., Flare Valve 2 Way 1/4"
A
50059014482
M4LC 007BR A04016014786 20 Assy., Flare Valve 3 Way 3/8"
M4LC 010BR A04019010747 M4LC 007 / 010BR A50059014485
M4LC 015BR
A
04019010748
A
ssy., Flare Valve 3 Way 1/2"
10 Rubber Grommet M4LC 015BR A50059014490
M4LC 007 / 010BR A11044000272
M4LC 015BR
A
11054000271
