Model: M4LC 020BR / 025BR
No. Descriptions Part No No. Descriptions Part No
1 Back Grille
A
50014043394 12
A
ssy., Restrictor Valve
2 Top Panel
A
01010011397 M4LC 020BR
A
50024042691
3
A
ssy., Condenser Coil M4LC 025BR
A
50024034401
M4LC 020BR
A
50024021529 13
A
ssy., Partition
A
50014012920
M4LC 025BR A50024033948 14 Assy., Terminal Box Panel A50044049929
4 Bracket, Motor Mounting
A
01010011398 15
A
ssy., Side Panel
A
01010011395
5 Fan Motor A03039000057 16 Assy., Access Panel A50124017615
6 Fan Blade
A
03019000016 17 Flare Valve Mounting Plate
A
01014036061
7
A
ssy., Front Panel
A
50014045826 18 Flare valve 3-way 5/8"
A
50059014487
8
A
ssy., 4 Way Valve
A
05019004158 19 Flare Valve 2-way 1/4"
9 Compressor M4LC 020BR A50059014482
M4LC 020BR A04019010653 Flare Valve 3-way 3/8"
M4LC 025BR
A
04019010654 M4LC 025BR
A
50059014483
10 Rubber Gromme
t
A
11054000271 20 Sensor, Outdoor Defrost
A
50134039416
11 Assy., Base Pan A50014013143
