32
9.
Conversion from
Old
Sequential Board
to
New Sequential
Board
(For
wiring up
to
1000 meters)
9.1
Sequential Main
Board
SQMB01 (Old
V
ersion)
9.2
Sequential Main
Board
SQMB01 (New
V
ersion)
U8
J1 & J2
Rework instruction:
SQMB01 (Main Board) from
old version t
o new version
Step 1:
Remov
e Jumper J1 and J2.
Step 2:
A
dd P
ar
t:
2051-MAX1483
IC :MAX1483 to U8
32
34
Table of Contents
Table of Contents
2
Model Name
3
Product Name Description
3
Nomenclature
4
Indoor Unit
4
Conversion Table
7
Controller Development History
10
Handset Operating Guide
12
Operation Guide
14
G11
16
G17
18
Slm3
20
Operating Guide
22
Sequential LCD
22
Netware 3
24
Controller Configuration
26
Auto Random Restart
26
Hot Keep Selection
27
Auxiliary Heater Conversion
28
Multi Split Conversion
29
Sequential Controller
30
Chilled Water Fan Coil Unit - W1V3
35
Chilled Water Fan Coil Unit - W2.0
36
Service Diagnosis
37
Self Diagnosis Table
37
General Check
57
General Troubleshooting Guide
58
Appendix
65
Resistance - Temperature Characteristic
65
