33
9.3
Sequential Main
Board
SQMB01 (New
V
ersion)
9.4
Sequential LCD
Panel
SQ-LCD (New
V
ersion)
P
ar
t:
2051-MAX1483 IC
:MAX1483
Jumper J1 and
J2 remov
ed
SQL
CD (L
CD P
anel) from old to new
Step 1:
Remove Jumper:
J1,
J2
Step 2:
Add Chip Resistor
.
1/10W 5% 200K
to R8,
R9,
R10
Step 3:
Add P
ar
t:
1000000030
IC:
SMD MAX1483CSA to U4
33
35
Table of Contents
Table of Contents
2
Model Name
3
Product Name Description
3
Nomenclature
4
Indoor Unit
4
Conversion Table
7
Controller Development History
10
Handset Operating Guide
12
Operation Guide
14
G11
16
G17
18
Slm3
20
Operating Guide
22
Sequential LCD
22
Netware 3
24
Controller Configuration
26
Auto Random Restart
26
Hot Keep Selection
27
Auxiliary Heater Conversion
28
Multi Split Conversion
29
Sequential Controller
30
Chilled Water Fan Coil Unit - W1V3
35
Chilled Water Fan Coil Unit - W2.0
36
Service Diagnosis
37
Self Diagnosis Table
37
General Check
57
General Troubleshooting Guide
58
Appendix
65
Resistance - Temperature Characteristic
65
