Outdoor Unit (MLCX Series)
All dimensions are in mm / (in)
Dimension A B C D E F G H I J K L M N O
10 / 15C / CR 700 521 250 485 175 36 95 93 86 68 441 130 111 15 18
(27,5) (20,5) (9,8) (19,1) (6,8) (1,4) (3,7) (3,6) (3,3) (2,6) (17,3) (5,1) (4,3) (0,5) (0,7)
3
(0,1)
B
EF
NCN
KLL
M
30
(1,2)
A
D
19
(0,7)
C
GH
I
J
O
80
(3,1)
65
(2,6)
