McQuay WSC 087

10 IM 1128-2
Figure 3, Suction and Discharge Piping
R331311308C0100
BOLT-ON
BLOCKOFF PLATE
TYPE II
UNITS RECEIVE
SLIP-ON ASME
FLANGES
TYPES II & III
TYPES I & II
TYPES I & II
VICTAULIC
BLOCKOFF PLATE
INSTALL SUCTION
PIPING
EVAPORATOR AND CONDENSER ARE EVACUATED
AND CHARGED WITH 30 PSI OF HELIUM.
TYPES I & II
