McQuay WSC 126 User Manual

42 IM 1128-2
LABEL
DESCRIPTION
LOOSE
PARTS
QTY.
FROM - TO
REF. DWG.
FACTORY
NOTES
STEEL PIPE ASSY'S
SUCTION LINE
1
COMPRESSOR TO
EVAPORATOR
R331311308
REMOVE AND
CRATE
DISCHARGE LINE
1
COMPRESSOR TO
CONDENSER
R331311308
REMOVE AND
CRATE
DISCHARGE NOZZLE
1
IN DISCHARGE LINE
R331311308
REMOVE AND
CRATE
CHECK VALVE
1
IN DISCHARGE LINE
R331311308
REMOVE AND
CRATE
LABEL
DESCRIPTION
LOOSE
PARTS
QTY.
FROM - TO
REF. DWG.
NOTES
MISCELLANEOUS
PART NO.
073244408
TOUCH- UP SPRAY PAINT
CANS
12
001358000
WIRE TIES
100
070183501
WIRE TIE STICK-ON MOUNTS
50
McQuay LONMARK LABEL BAG
1
LITERATURE AND SCHEMATIC
IN MANILLA ENVELOPE
1
STARTER SHROUD
1
IF PRESENT
STARTER BRACKETS
2
IF UNIT
MOUNTED
TERMINAL SHROUD
1
IF PRESENT
ISOLATOR PADS
6
OPERATOR INTERFACE
PANEL
1
LCD SUPPORT ARM
1
POWER CABLES
3 OR 6
IF UNIT
MOUNTED
CONTROL BOX WATER
HOSES
2
COMPRESSOR 4 WAY VALVE
ASSY
1
COMPRESSOR INSULATION
KIT
1
SHEET INSULATION (HEADS,
BRACKETS ETC.)
X SQ. FT.
SEE BOM FOR
QUANTITY
O-RINGS AND GASKETS IN
PLASTIC BAG
1
735030433
OIL CONTAINERS (5 GAL. EA.)
X
SEE BOM FOR
QUANTITY
000986000
INSULATION GLUE (1 GAL.)
1
074646106
PRESSTITE THERMAL MASTIC
2
070217402
V-740 THERMAL COMPOUND
2
KNOCKDOWN REFERENCE
DWG. PACKET
1
Continued on the next page.
