MCS-Pressure Transducer (old style with washer)
1. PACKAGING
• Transducer with Washer
2. TRANSDUCER AND PARTS
• Transducer, black protector and washer
removed from bag
3. TRANSDUCER PARTS
• Transducer parts before installation
Black Cap
Removed
Copper
Washer
4. PRIOR TO INSTALLING ON FITTING
• Showing typical angle valve on Hanbell Screw
Compresser where Transducer will
be placed.
5. PLACEMENT OF WASHER
• Showing correct placement of washer,
make sure placement of washer is with
bevel out.
6. TRANSDUCER MOUNTED TO ANGLE VALVE
• Finished placement of MCS-TRANSDUCER
